Power strip SPS 4F+6F PDU SCH+C13/C14
35,38 €
VAT included · Delivery to mainland Spain and the Balearic Islands
Shipping: 6,05 €
Typical transit after dispatch: 24 h to mainland Spain and 48 h to the Balearic Islands. Estimate depends on destination and availability.
In stock
Total including shipping: 41,43 € · Free shipping from 313,34 €
Salicru SPS 4F+6F power distribution unit with 4 Schuko and 6 IEC C13 outlets, IEC C14 input and 1U 19" format. Designed to distribute power from a UPS, generator or mains to racks and servers.
About this product
The Salicru SPS 4F+6F PDU is a power distribution unit designed to distribute power from a UPS, a generator or the mains to multiple devices, such as network racks and servers in data centers and computer rooms. It has 4 Schuko outlets and 6 IEC C13 outlets, with an IEC C14 input and an illuminated on/off switch with a protective cover to prevent unintended operation. Its aluminium housing provides robustness and lightness, and the multi-position system allows the mounting brackets to be fixed in different depth and tilt combinations. The entire range is in 1U 19" format and supports horizontal or vertical installation in the rack or cabinet. It operates at 100/250 V AC and 50/60 Hz, with a rated current of 10 A, and the power cable is 1.5 m long. It includes child protection in the outlets and LED indicators. The operating temperature is 0 °C to 50 °C and the protection degree is IP20.
What can you use it for?
- Distribute power from a UPS, generator or the mains to several devices in network racks and servers in data centers or computer rooms.
- Install it in a 19" rack in 1U format, horizontally or vertically, depending on the cabinet configuration.
- Connect devices with a Schuko plug and equipment with an IEC C13 connector on the same unit, provided the total load does not exceed the 10 A rated current.
Its strengths
- It includes 4 Schuko outlets and 6 IEC C13 outlets, allowing you to power a combination of devices with different connector types.
- The illuminated switch with protective cover helps prevent accidental operation.
- The aluminium housing provides robustness and lightness, and the multi-position system facilitates rack mounting.
Things to consider before buying
- The input is IEC C14, so you will need a cable or outlet compatible with this connector to power the PDU.
- The rated current is 10 A; if you plan to connect high-consumption equipment, check that the total does not exceed this limit.
Product questions
What type of outlets does this PDU include?
It includes 4 Schuko outlets and 6 IEC C13 outlets. The input is IEC C14.
Can it be installed in a 19" rack?
Yes, the entire range is in 1U 19" format and supports horizontal or vertical installation in the rack or cabinet.
What rated current does it support?
The rated current is 10 A. The rated voltage and frequency are 100/250 V AC and 50/60 Hz.
ALMC analysis prepared with AI assistance using the supplier’s product information. It is not a product test or a customer review. Check the specifications and confirm the compatibility you need.
Technical specifications
Los modelos SPS PDU incorporan un interruptor de encendido/apagado con iluminación y tapa de protección para evitar acciones no deseadas.
Las tipos de bases de toma disponibles son schuko, IEC, UK y combinaciones entre ellas. La carcasa es de aluminio, lo que confiere robustez y, a la vez, ligereza en peso. El sistema multiposición permite la instalación de los soportes de fijación en múltiples combinaciones, tanto en profundidad (6 posiciones) como en inclinación (5 posiciones).
Toda la gama es en formato 1U de 19” y las opciones de instalación horizontal o vertical en el bastidor/rack.
Prestaciones
- Perfiles de aluminio de 1U - 19".
- Facilidad de instalación y conexión.
- Múltiples posiciones en profundidad (6 posiciones).
- Múltiples posiciones de inclinación (90º / 45º / 0º / -45º / -90º).
- Interruptor iluminado de encendido/apagado.
- Alimentación a 250 V AC - 50/60 Hz.
- Tomas schuko, UK e IEC disponibles y combinatorias.
- Tapa de protección del interruptor de encendido/apagado.
- Otras configuraciones bajo demanda.
- Instalación vertical u horizontal.
- Calidad de conexión y máxima seguridad en las tomas.
| Marca | Salicru |
| Modelo | 680CA000006 |
| Características | - Corriente nominal (A): 10 - Tensión / frecuencia nominal 100 / 250 V AC - 50 Hz / 60 Hz - Tipo de toma de entrada: IEC C14 - Tipo de toma y cantidad: Schuko (4) + IEC C13 (6) - Interruptor de encendido/apagado - Longitud cable de alimentación (m): 1,5 - Protección infantil en las tomas - Indicadores LED Generales - Temperatura de trabajo: 0º C ÷ 50º C - Temperatura de almacenaje: -15º C ÷ 60º C - Humedad relativa: Hasta 95%, sin condensar - Altitud máxima de trabajo: 2.400 m.s.n.m. (degradación de potencia hasta 5.000 m) - Grado de protección: IP20 - Instalación: Soportes de fijación de 3 posiciones 0º o ±45º Normativa - RoHS Sí - Seguridad: IEC 60950 ; DIN EN 50525-2-11 ; IEC 61058-1:2002/A2:2008 - Gestión de Calidad y Ambiental: ISO 9001 e ISO 14001 Dimensiones y peso - Dimensiones(Prof x An x Alt): 51 × 443 × 44 mm - Peso: 0.8 Kg |
| Fecha de revisión | 24-04-2020 por MSB |
Product identifiers
| Reference | AELREG0083 |
|---|---|
| EAN | 8436035929351 |
| Part number | 680CA000006 |
| Manufacturer | Salicru |
Delivery, returns and warranty
We deliver to mainland Spain and the Balearic Islands. Shipping costs are shown before payment.
14 calendar days to withdraw without giving a reason. See conditions and exceptions. How it works.
3-year statutory warranty.
